AIR MOTOR TAM4 SERIES
HOT ITEM (STANDARD TYPE) : TAM4-010S , TAM4-015S , TAM4-030S

An air motor with a grease-filled type that can be installed in any direction.
Due to the grease filling type, the mounting direction is free. (Refueling with an air bricator is required)
Since it has a built-in balancer mechanism, operation with less vibration can be obtained.
★ Option : With Flange, With Brake, With decelerator or With brake and decelerator

TAM4-010S
Power :
73.5 W
Torque : 0.637 Nm
Rotation : 1100 R.P.M.
Stop Torque : 1.18 Nm
Start Torque :0.686 Nm

TAM4-015S
Power : 125 W
Torque : 1.37 Nm
Rotation : 900 R.P.M.
Stop Torque : 2.94 Nm
Start Torque : 1.96 Nm

TAM4-030S
Power : 228 W
Torque : 2.94 Nm
Rotation : 750 R.P.M.
Stop Torque : 5.88 Nm
Start Torque : 4.71 Nm

Download PDF Catalog

More information, Please contact us
